Rugged Solid-State Flash Disks
Reliability You Can Count On To Succeed

M-Systems provides innovative rugged electronic solid state disks based on flash memory. The Fast Flash Disk (FFDâ„¢) product family is drop-in replacements for mechanical Serial ATA, Ultra ATA/IDE, Narrow and Wide Ultra320 SCSI flash drives, available in standard 1.8", 2.5" and 3.5" form factors with capacities ranging from 128MB to 352GB, burst performance up to 320MB/s and read/write performance up to 45MB/s.

The FFD's outstanding performance is based on M-Systems' state-of-the-art TrueFFS® technology that provides true disk emulation, high read and write transfer rates, enhanced endurance and maximum data integrity under power cycling conditions.

Designed for systems that require top reliable data storage operating under harsh environmental conditions, FFD is the perfect storage solution for military and aerospace, tactical computers and rugged laptops, telecommunications, blade servers and computing systems. M-Systems' FFDs have been integrated by designers since 1997 as a storage solution for data recorders, moving maps, sonar, radar, fire control systems, black boxes, C4ISR, airborne reconnaissance systems, rugged laptops, tactical computers, routers and gateways, blade servers, workstations and servers in air forces, navies and armies worldwide.

M-Systems' FFD product line

Among M-Systems FFDs customers are: AirShow, Aselsan, Astronautics, Boeing, Bombardier, Cisco Systems, Daewoo, DSO, DSTA, ECI Telecom, Elbit, Elta, Ericsson, FLIR Systems, GE, General Dynamics, Harris, Hitachi, IAI-Israel Aircraft Industries, IBM, Kontron, L-3, LG, Lockheed Martin, Matsushita, Melco, Miltope, Motorola, NEC, Nortel Networks, Northrop Grumman, OKI, Rafael, Raytheon, RUAG Aerospace, SaabTech, Siemens, Smiths Aerospace, Sonus networks, SES, Staubli, Tadiran Telecom, Targa, Thales Computers & Toshiba.

FFD 2.5" Serial ATA flash drive

FFD 3.5" Ultra320 SCSI flash drive

FFD 2.5" Ultra ATA flash drive

IDE 4000 2.5" flash drive

FFD (Fast Flash Disk) Product Line Highlights

• Flash Solid-State Drives with no moving parts
• TrueFFS® Technology for disk emulation
• 1.8", 2.5" and 3.5" standard Form Factors
• Serial ATA, Ultra ATA/IDE, Narrow and Wide Ultra320 SCSI interfaces
• Up to 320.0 MB/s Burst R/W rate
• Up to 45.0 MB/s Sustained Read rate
• Up to 40.0 MB/s Sustained Write rate
• Access time <0.02 msec
• Up to 352GB disk capacity
• Supporting hot swapping (hot insertion)
• Slim packages down to 7.4mm' case height
• Standard connector type : SATA, 40, 44, 50, 68 and 80 pins
• 6U VME, 6U and 3U Compact-PCI and PMC solid-state memory boards
• Sun Microsystemsâ„¢ Solarisâ„¢ Ready

High Reliability and Extended Life Expectancy

• Field MTBF exceeds 1,000,000 hours
• Maintenance-free solution (lower Total Cost of Ownership)
• On-the-fly EDC/ECC based on BCH algorithm
• BER (Bit Error Rate) of 10^-20
• Built-in power-up self-test with manual and automatic self-diagnostics
• Data integrity under power cycling
• Bad block mapping-out algorithm
• Extended endurance >5,000,000 Write/Erase cycles; Read unlimited
• Dynamic Wear-leveling
• Compliance: CE, UL and FCC Class B
• 5-year warranty

• No moving parts
• Operating temperature range: -40°C to +85°C
• Storage temperature range: -55°C to +95°C
• Operating altitude: +80,000ft
• Humidity: 5% to 95% relative, non-condensing
• Operating shock conditions: 1,500G per MIL-STD-810F
• Operating vibration conditions: 16.3G RMS Per MIL-STD-810F (Random 20Hz to 2,000Hz, 3 vibration axes)

Enhanced Data Security

• Quick security erase - ability to erase the entire disk media in seconds
• Auto-resume security erase on power interrupt
• Partial / Selective security erase
• Secure Erase during power down
• Sanitize comply with DoD NISPOM 5220.22-M, NSA 130-2, Air Force AFSSI 5020,
• Army 380-19, Navy NAVSO P-5239-26 and IREC (IRIG) 106
